Aluminum 6082-T6

Material type: Metal, Corrosion resistance, Non-magnetic

Aluminum alloy 6082-T6 boasts high strength and excellent corrosion resistance, and is widely used in various fields such as transportation (truck bodies, ship components, rail transit), structural engineering (tower buildings, pipe parts), hardware and electronic accessories, and sports equipment manufacturing..

Process compatibility

CNC Milling CNC Turning

Material Color

Silver white

Material advantages

It has medium-high strength, excellent corrosion resistance, good weldability and processing performance, and is suitable for transportation, marine engineering and construction structures, etc.

Material shortcomings

The internal quenching residual stress is high, the quenching sensitivity is relatively high, the cold bending ability is average, and it is not suitable for deep stretching or small R bending. The bending rebound is relatively large.

Recommended description

6082-T6 is a type of 6-series high-strength aluminum alloy. Its strength is superior to 6061-T6. It has excellent machinability, stable corrosion resistance and anodization performance, and offers better cost-effectiveness compared to 7075. It is suitable for CNC processing fixtures and structural components of medium-sized dimensions and medium to high loads.

Properties

Name
Ultimate tensile strength	310 – 330 MPa
Yield strength	270 – 280 MPa
Young's modulus (modulus of elasticity)	69 – 70 GPa
Elongation at break	6% – 10%
Corrosion resistance	High
Magnetism	Non-magnetic
Weldability	High
Maximum service temperature	170 °C
Thermal expansion coefficent	23.4 × 10⁻⁶ /°C
Thermal conductivity	160~180 W/(m⋅°C)
Electrical resistivity	3.8 - 4.1 μΩ·cm
Post-Processing	NA
Anodizing compatibility	Suitable
