On-site PCB Assembly - protects your design Prototype and small volume PCB assembly made easy

71,000+

Paying Customers

235,000+

Customers Worldwide

Just like PCB business, our PCBA services also specialize in prototyping and small-volume production, making PCBWay the one-stop destination of boards fabrication and assembly. This arrangement makes your R&D work easy and time-saving. Our professional engineers and technicians will work closely with you through our customer service people to ensure the best quality and quickest possible lead time. Fulfilling hundreds of orders daily from around the world, we have established us as the leading supplier of PCB and PCBA services for our consistent quality and excellent services.

PCBWay PCBA capabilities: SMT Assembly, BGA Assembly, Through-Hole Assembly, Mixed Assembly, Rigid Flex PCB Assembly Services.Compliant with a wide range of standards including IPC 610 Class 2 and Class 3.

  • PCB Assembly Specialists

    Our complete assembly capabilities
    span BGA, Micro-BGA, QFN and
    leadless package parts.

  • Fast Turn Times

    Prototype PCB assembly fast. Kitted and
    Turn-Key options available. Quote and
    order online, any time.

  • Turnkey & Quality

    X-Ray Inspection,AOI & Functional Testing
    Fabrication, parts sourcing and assembly.
    They come back to you ready to go. Easy!

  • Delivery Guarantee

    Time is money. PCBWay delivery
    guarantee ensures you get what you need,
    when you need it.

  • SMT Assembly Capabilities

    Quote Now

    SMT Assembly -- Components are mounted by placing them directly onto the PCB's surface. We have the capabilities to assemble
    SMT prototype PCBs in small production runs with manual and/or automated SMT production processes, including single- or
    double-sided component insertions. Our production facilities can assemble the following SMT types:

    • Ball Grid Array (BGA)

    • Ultra-Fine Ball Grid Array (uBGA)

    • Quad Flat Pack No-Lead (QFN)

    • Quad Flat Package (QFP)

    • Small Outline Integrated Circuit (SOIC)

    • Plastic Leaded Chip Carrier (PLCC)

    • Package-On-Package (PoP)

    • Small Chip Packages (pitch of 0.2 mm)

    SMT Assembly
  • BGA Assembly Capabilities

    Quote Now

    Four automated placement systems available with Vision Systems capable of inspecting solder ball coverage. One automated
    systems available with 3-D laser capable of inspecting solder ball height Automatic placement of CBGA, PBGA and MBGA
    Verification of BGA’s using Phoenix real-time x-ray system. Ball Grid Array (BGA) style circuit boards, which used small circular balls
    of solder to allow the flow of electricity between parts of the circuit. This brought with it a number of advantages to PCB assembly:

    Higher-density circuits: As through-hole circuits were more densely-populated,
    soldering them accurately without crossover or short-circuits became nearly
    impossible. Heat conduction: BGA circuits allow heat to pass much more easily
    from the integrated circuit outwards, reducing overheating problems. Lower
    inductance: Because each solder ball in an BGA circuit is generally only a
    handful of millimeters large, problems from interference within the circuit are
    greatly minimized.

    BGA ASSEMBLY
  • Through-Hole Assembly

    Quote Now

    Through-Hole Assembly -- Components are mounted by inserting leads into holes which are then covered by solder.
    Automated Through-Hole Assembly Manual Through-Hole Assembly

    We had traditional through-hole circuitry, with leads being directly threaded through pre-made
    holes in the printed circuit board. This was simple enough to be done by hand, but Ball Grid
    Array (BGA) PCB extremely inefficient in terms of optimizing space usage.

    Through-hole mounting techniques are now usually reserved for bulkier or heavier components
    such as electrolytic capacitors or semiconductors in larger packages such as the TO220 that
    require the additional mounting strength, or for components such as plug connectors or
    electromechanical relays that require great strength in support.

    Through-Hole
  • Mixed Assembly Advantages

    Quote Now

    Mixed Assembly -- Through-Hole, SMT and BGA components are housed on the PCB.

    Single- or double-sided mixed technology or SMT (Surface Mount) for PCB assembly Single- or double-sided BGA and micro-BGA
    installation and rework with 100% X-ray inspection

    PCB board components, including all types of BGAs, QFNs, CSPs, 0201, 01005,
    POP, and Pressfit Components in small quantities

    Part Polarity Capacitors, SMT Polarized Capacitors, and Through-Hole Polarized
    Capacitors
    Rework Capabilities: Removing & Replacing BGA’s & MBGA’s, Experienced with
    Ceramic & Plastic BGA’s, Reballing BGA’s & MBGA.

    Mixed Assembly
  • SMT ASSEMBLY CAPABILITIES
  • BGA ASSEMBLY CAPABILITIES
  • THROUGH-HOLE ASSEMBLY
  • MIXED ASSEMBLY ADVANTAGES
No. Types Of Assembly File Format Component Footprinr Component Package Testing Produres Produres Others
1 SMT ASSEMBLY Gerber RS-274X 0201,0402,0603... Reels Package Visual Inspection Lead-Free(Rohs) Custom Reflow Profile
2 SMT & THT Assembly BOM(.xls,.csv,.xlsx) BGA,QFN,QFP,PLCC Cut Tape Package X-Ray Inspection Leaded Solder Standard Reflow Profile
3 2 sided STM,THT Assembly Pick-N-Place/XY file SOIC,POP...Connectors Tube and Tray AOI,ICT(In-Circuit Test) Reflow Soldering Smallest Size:0.2"x0.2"
4 Mixed Assembly ... Small Pitch of 8 Mils Loose parts and bulk Functional Testing Wave Soldering Largest Size:15"x"20
