ardu keys

I'm so happy with the assembly here. Everything is soldered perfectly and as first timer pcb designer I did not have to worry about soldering and maybe make mistakes for my project, all I had to do is design, find components and send the BOM, PCBWay did the rest and I didn't have to wait much time. This is for a project (extra keys to bind) that I developed here: https://github.com/alessandro-ooo/ardu-keys and I want to show it to companies in my portfolio and linkedin, I just have to finish a few things and it's done, and thanks to the assembly feature I could focus on other things while the soldering and everything was being made, which is perfect. I'll leave some vids or pics.



Sep 01,2026
