Description
SummerCart64 - a fully open source Nintendo 64 flashcart
PLEASE SELECT PCB OPTIONS LISTED BELOW MANUALLY BEFORE PLACING ORDER
THIS IS VERY IMPORTANT
PCB REQUIREMENTS
- PCB thickness: 1.2 mm
- Surface finish (plating): ENIG (Hard gold for edge connector is recommended but it's very expensive, ENIG is good enough)
- Edge connector: yes
- Beveled edge connector: yes, 45° (other angles also should work OK)
IF YOU WANT PCBs ASSEMBLED WITH COMPONENTS YOU HAVE TO SELECT "PCB+Assembly" OPTION ON THE RIGHT ABOVE "Add to cart" BUTTON
Ever wanted to make your own customizable Nintendo 64 flashcart? Now you can! This project aims to be a great fit for both gamers and homebrew developers.
Features:
- 64 MiB SDRAM memory for game and save data
- 16 MiB FLASH memory for bootloader and extended game data
- 8 kiB on-chip buffer for general use
- ~23.8 MiB/s peak transfer rate USB interface for data upload/download and debug functionality
- ~23.8 MiB/s peak transfer rate SD card interface
- EEPROM, SRAM and FlashRAM save types with automatic writeback to SD card
- Battery backed real time clock (RTC)
- Status LED and button for general use
- 64DD add-on emulation
- IS-Viewer 64 debug interface
- N64 bootloader with support for IPL3 registers spoofing and loading menu from SD card
- Enhanced UltraCIC_C emulation with automatic region switching and programmable seed/checksum values
- PC app for communicating with flashcart (game/save data upload/download, feature enable control and debug terminal)
- UNFLoader support
- Initial programming via UART header or dedicated JTAG/SWD interfaces
- Software and firmware updatable via USB interface
- 3D printable plastic shell
INITIAL PROGRAMMING
Specific programming instructions are located in linked GitHub repository under docs/06_build_guide.md location.
HELP / FAQ
For help and support please go to linked GitHub repository and check discussions tab. If your question isn't already asked feel free to add it.
