Flex & Rigid-Flex PCBs Manufacturing Capabilities

PCBWay provides fully customizable flex & rigid-flex circuit boards, allowing clients to select the number of layers, thickness, materials, and surface finishes, ensuring that even the most complex designs can be accommodated with ease and precision.

Flexible PCB

Rigid-Flex PCB

Feature	Capability
Layer	1-12
Board thickness (without stiffener)	4‐40 mil
Tolerance of single layer	±1.0mil
Tolerance of double‐layer (≤12mil)	±1.2 mil
Tolerance of multi‐layer (≤12mil)	±1.2 mil
Tolerance of multi‐layer (12mil‐32mil)	±8%
Tolerance of board thickness (including PI stiffener)	±10%
Min. board size	0.0788” 0.1576” (without bridge) 0.3152” 0.3152” (with bridge)
Max. board size	8.668” * 27.5”
Impedance control tolerance	±4Ω (≤50Ω), ±7% (>50Ω)
Min. coverlay bridge	8 mil
Min. bend radius of single layer	3‐6 times of board thickness
Min. bend radius of double‐layer	7‐10 times of board thickness
Min. bend radius of multi‐layer	10‐15 times of board thickness
Min. mechanical drill hole	4 mil
Inner Layer Trace/ Space	2/ 2 mil
Outer Layer Trace/ Space	2/ 2 mil
Solder mask color	Green\Black
Surface treatment	HASL, ENIG, ENEPIG, Electrolytic Nickel Gold, Soft gold, Hard gold, Immersion silver and OSP, Immersion tin
Laser accuracy (Routing)	±2 mil
Punching accuracy (Routing)	±2 mil ‐ ±6 mil

Feature	Capability
Layer	26L
Min. Track/Spacing	0.065 mm/0.065 mm
Min. Hole/pa Size	0.10/0.35 mm
Rigid-Flex Thickness	0.25-6.0mm
MAX CU Thickness	4 OZ
Drilling accuracy	+/-0.05 mm
PTH diameter tolerance	+/-0.05 mm
MAX WPNL SIZE	620 mm × 500 mm
Finish Copper (Flex Part)	0.5-2oz
Finish Copper (Rigid Part)	1-4oz
Surface treatment	ENIG, Electric gold, IM-Ag, Electric Ag, HASL, HASL-LF, IM-Sn, Electric Sn, OSP, Caborn, Pt, NI-Pd-AU
Max board thickness: PTH diameter	13:1
Build time	7-20 days
RFQ	1-2 days

Material:	PI, FR-4
Layers:	12
Thickness:	1.6mm
Min Hole Size:	0.25mm
Min Track/Spacing:	3/3mil

Layers:	2
Thickness:	0.1mm
Min Hole Size:	0.2mm
Min Track/Spacing:	3/3mil
Surface Finish:	Immersion gold(ENIG)

Material:	PI, FR-4
Layers:	4
Thickness:	1.6mm
Min Hole Size:	0.75mm

Structure:	1+2F+1
Inner layer LW/SP:	3/3mil
FPC Thickness:	25um, no IVH hole design
Rigid-Flex Thickness:	0.275 +/- 0.028mm
Surface Finish:	ENIG + Silver Paste

Structure:	1+2F+1
Inner layer LW/SP:	3/3mil
FPC Thickness:	25um, with IVH hole design
Rigid-Flex Thickness:	0.295 +/- 0.052mm
Surface Finish:	Immersion gold(ENIG)

PCB Type:	Rigid-Flex Board
Sample Project:	Telecom
Structure:	(2+1+2F+1+2) HDI
Layers:	8 layered Rigid flex
Technical characteristics:	Double-sided flex inner layer core

Layers:	12 Layers(4R+4F+4R)
Finished Thickness:	1.70mm
Min Hole:	0.20mm
Technical characteristics:	HDI Rig-flex

Layers:	2R+2F
Min Line Width/Spacing:	3/3mil
Min Hole:	0.25mm
Finished Thickness:	1.2mm
Product use:	Industrial control

Layers:	4 Layers(1R+2F+1R)
Finished Thickness:	0.35mm
Min Line Width/Spacing:	3/3mil
Min Hole:	0.20mm
Product use:	Industrial control

Layers:	6 Layers(2R+2F+2R)
Min Line Width/Spacing:	3/3.5mil
Min Hole:	1.00mm
Product use:	Spend products

Layers:	10 Layers(4R+2F+4R)
Finished Thickness:	1.0mm
Min Line Width/Spacing:	3/3mil
Min Hole:	1.20mm
Product use:	Industrial control

Layers:	14 Layers(10R+3F+1R)
Finished Thickness:	2.6mm
Min Line Width/Spacing:	3/3mil
Min Hole:	0.20mm
Max Aperture Ratio:	13:1
Technical characteristics:	Thickness is dissymmetry
