Build Time: 2-3 Business Days
PC-FR
Material type: Plastic, Thermoplastic, Polycarbonate (PC), Flame Retardant
PC-FR is a flame-retardant polycarbonate filament engineered for high-performance 3D printing where safety, strength, and heat resistance matter. Tested to meet the UL 94-2023 V-0 standard, the top level of flame resistance for 3D printing filament, PC FR is designed to prevent or slow flame propagation with exceptional self-extinguishing properties. Its durability makes it ideal for industrial components, protective casings, and high-temperature environments in sectors like automotive, electronics, and manufacturing.
Process compatibility
Material Color
Black
White
Gray
Material advantages
Top-tier flame retardancy: Tested to meet the UL 94-2023 V-0 standard, the highest level of flame resistance for 3D printing filament. UL 94 is a plastics flammability standard established by Underwriters Laboratories (USA). V-0—the highest UL 94 V rating—indicates that burning stops within 10 seconds on a vertically positioned specimen, with dripping particles allowed as long as they are not ignited.
Engineering-level mechanical properties: An engineering-grade material with toughness comparable to PAHT-CF. Its exceptional stiffness and strength make it a top choice for structural components and protective casings.
High heat resistance: Heat Deflection Temperature of 113 °C, suitable for parts exposed to high temperatures, such as motor covers and electronic enclosures.
Water resistant.
Oil and grease resistant.
UV resistant.
Dimensional stability.
Material shortcomings
Easy to warp: PC-FR has a tendency to warp during printing, especially in large or thick parts.
Drying required before use: PC FR must be dried before use and kept moisture-free during the printing process to ensure the best print quality and consistent finish.
Enclosure recommended: An enclosed chamber helps maintain a consistent temperature around your print, reducing warping and improving print quality.
Low moisture tolerance: PC has a high moisture absorption rate, which can cause poor layer adhesion and brittleness if not properly dried.
Recommended description
PC-FR is a high-performance, flame-retardant polycarbonate filament for FDM 3D printing. It offers exceptional flame retardancy (UL 94-2023 V-0), impact resistance, heat stability (HDT 113 °C), and engineering-level mechanical properties comparable to PAHT-CF. It is ideal for industrial components, protective casings, electrical enclosures, automotive parts, and safety-critical applications. However, it requires drying before use, an enclosed printer for best results, and proper ventilation during printing.
Properties
Name
Density 1.18 g/cm³
Vicat Softening Temperature 114 °C
Heat Deflection Temperature 113 °C
Melting Temperature 225 °C
Melt Index 26.4 ± 2.7 g/10 min
Tensile Strength 60 ± 4 MPa
Breaking Elongation Rate 2.4 ± 0.3%
Bending Modulus 1890 ± 70 MPa
Bending Strength 90 ± 4 MPa
Impact Strength 55 ± 2.1 kJ/m²
Common applications
• Electrical enclosures and housings
• Functional prototypes and engineering parts
• Automotive interior components
• Industrial jigs and fixtures
• Robotics and mechanical assemblies
• Safety-focused components requiring flame resistance
• Structural components and protective casings
