Example printed circuit boards manufactured by us.

We have the PCB manufacturing capabilities to build simple to complex bare boards.
Please review the example printed circuits below and let us know if you have any
questions or would like a formal quote.

Focus on high-end PCB design, R&D, production, sales, provide customers with high-level, high-speed, high-frequency, high-end,
high-density, high-difficulty HDI PCB design and other types of PCB proofing, customization, board manufacturing and bulk online
order purchase service. The products have covered high-end HDI buried blind hole PCB, 5G communication PCB board, high frequency
and high speed PCB, optical module PCB, semiconductor test, aerospace PCB circuit board and many other fields.

原图
Mouse over to zoom in

UAV PCB control main board

Applications
Drone
Features
3 times laser drilling, 3 times pressing
Material
S1000-2M
Layers
10 Layers
Thickness
1.0±0.1mm
Min Hole Size
Laser blind hole 0.1mm, mechanical hole 0.2mm
Min Track/Spacingh
75/95um
Minimum board thickness and hole ratio
5:1
Surface Finish
Immersion gold(ENIG) 0.05um
Quote Now
Product Details

The UAV controller PCB is made of Shengyi S1000-2M material and produced by the surface immersion gold process. It is mainly used in the field of civilian UAVs.


Related Products View more >>
  • UAV camera high-density PCB

    12 layers, Material: S1000-2M+C501, Thickness: 1.6±0.1mm

  • UAV PCB ESC board

    12 layers, Material: S1000-2M, Thickness: 2.2±0.2mm
