QSX40 NOVA
QSX40 NOVA is a compact 40-meter QRP transceiver project inspired by classic BITX and Lazer style architectures using bidirectional amplifier stages and a simple, practical RF design philosophy.
The project keeps the traditional analog signal path used in many successful homebrew transceivers while adding modern frequency control through an Si5351 PLL synthesizer module.
The design focuses on:
Bidirectional amplifier stages
Simple and reproducible construction
Compact PCB layout
40m amateur band operation
QRP power levels
Easy experimentation and modification
DIY friendly architecture for home constructors
QSX40 NOVA is intended as an educational and experimental platform for radio amateurs who enjoy building, understanding, and improving classic QRP transceiver designs with modern frequency synthesis.
For update and Gerber files
QSX40 NOVA
