Bitx40 Rx Rig — QRP Collaboration Project 01
Bitx40 Rx Rig — QRP Collaboration Project 01
This is a low-cost, experimental 40-meter SSB receiver developed as part of the QRP Collaboration initiative.
The project is focused not only on building a radio, but also on learning, experimenting, measuring, and sharing knowledge using EasyEDA Pro.
The design is being developed collaboratively, step by step, with different options and ideas being tested along the way.
Anyone interested in learning and participating is welcome to join us.
More information about QRP Collaboration, how to participate, and the project guidelines can be found in our Facebook group:
QrpCuba
https://www.facebook.com/groups/QrpCuba
Learn → Build → Share → Help → Grow.
