Description
PCB Rule with resistor color code, full color printed with the UV technology
This PCB project is a tool (Rule) and an electronic utility to remember the value of each color in the resistor color code palette.
(To order this PCB, send the [Product No.: W37275CCSH52 ] reference to PCBWAY engineers).
The Rule:
- The rule is a useful tool to measure up to 150 MM or 6 Inches, meaning the rule has 2 scales, one by each size.
The resistor color code:
- The pretty part of this PCB is without a doubt the beautiful colors printed over the PCB with the UV technology, which is useful for calculating the value of the resistor by checking the value of the corresponding color
