fpv audio-video 5.8GHZ vtx "transmitter" based on tx5823 with voltage regulator built in
8 channels 5.8GHZ Audio-Video transmitter circuit based on TX5823 very simple and easy to solder. contains a voltage regulator built in
note: by ordering any of my free project from pcbway you are supporting me to complete and publish my new project witch is an open source 10d0f flight controller board that supports mission planing, return to home, gps fix, baro fix , acro and auto level and much much more
Sep 06,2022
1,857 views
fpv audio-video 5.8GHZ vtx "transmitter" based on tx5823 with voltage regulator built in
a 8 channels 5.8GHZ Audio-Video transmitter circuit based on TX5823 very simple and easy to solder. contains a voltage regulator built in
