1 C1 68UF 600V 24 https://www.mouser.in/ProductDetail/Nichicon/LGN2X680MELB30?qs=vniZgrqwd6izXk8QjGGckg%3D%3D
2 R1 10M 1W 12
3 SLOW BLOW 6AMP FUSE 3
4 1.7mH CHOKE 9
5 NTE5817 1KV 6AMP 6
6 3 PIN TOGGLE WITCH 6
7 J7P1 1
8 J7P2 1
9 J7P3 1
10 C1T1P1,2 1
11 C1T2P1,2 1
12 C1T2P5,6 1
13 C1T1P3,4 1
14 C1T2P3,4 2
15 C2T1P1,2 1
16 C2T2P1,2 1
17 C2T2P5,6 1
18 C2T1P3,4 2
19 C3T1P1,2 1
20 C3T2P1,2 2
21 C3T2P3,4 1
