USBSID-Pico v1.3

About

USBSID-Pico is a RaspberryPi Pico/PicoW (RP2040) & Pico2/Pico2W (RP2350) based board for interfacing one or two MOS SID chips and/or hardware SID emulators over (WEB)USB with your computer, phone, ASID supporting player or USB midi controller.

Get in contact on Discord here: https://discord.gg/zG2rxXuT2g

View active Github discussions here: https://github.com/LouDnl/USBSID-Pico/discussions

Visit the Github page for more information: https://github.com/LouDnl/USBSID-Pico

PCB Features ~ v1.3

• Supports all MOS SID chips e.g. MOS6581, MOS6582 & MOS8580
• Supports SID chip replacements e.g. SIDKick-Pico, ARMSID & FPGASID, SwinSID.
• USBSID-Pico will by default generate a 1 MHz square wave using pio
• other clock speeds are configurable
• IO controlled Stereo/Mono switch, can be set in config or toggled during play with supported players
• SID1 audio left
• SID2 audio right
• Powered via USB
• Three separate voltage regulators for filtered voltages to the SIDS
• 1x fixed 5 volts and 2x 9 volts or 12 volts
• 5v stepup for clean 5v VCC to both SID chips
• Supports mixed voltage! e.g. you can use one MOS6581 (12v) together with one MOS6582 (9v) or MOS8580 (9v)
• 12v/9v jumper for each SID socket, defautls to 12v ~ inspired by SIDBlaster-Nano design
• Audio out filter as in the C64 schematics
• With optional 6581 resistor, solder the 6581 jumper pad in each audio circuit for this.
• Optional EXT-IN pulldown resistor as filter bypass to reduce filter noise for Digiplay on 8580 SID's
• SID socket placement is more spread out for:
• easier filter capacitor access
• optional ZIF sockets
• Better IO port layout
• Unused GPIO pins for optional future expansion boards
• IO5 pins for quad SID configuration
• Uart pins
• SID Ext in pins (requires closing the solder jumper on the bottom)
• Ground pin
• New soldermask art ;)

SID Playing

USBSID-Pico supports various ways of playing SID files.

• Out-of-the box playing is supported by using Deepsid by Chordian
• Out-of-the box playing is also supported by using C64jukebox by Kenchis , note that this is still in BETA.
• SidBerry is a command line SID file player for Linux & Windows with up to 4 SIDs supported (Windows version is buggy).

C64 emulators

Several Commodore 64 emulatores have official support

• Vice has official support starting at tag r45763 and up, up to 3 SIDs are supported in vsid and up to 4 in x64sc.
• JSidplay2 has official support in latest Java beta versions, up to 4 sids.
• Denise has official support in nightly builds and code, up to 4 sids.

And some have unofficial support through forks on my Github

• Unofficial support is added to a fork of sidplayfp which requires a fork of libsidplayfp
• Unofficial support is added to a fork of RetroDebugger, up to 4 SIDs are supported.

C64 Music trackers

Into creating chiptunes? USBSID-Pico is your board!

• You should be able to use the ASID fork of sidfactory2 without issues.
• When using Vice or RetroDebugger you can freely use applications like SID-Wizard for music creation.
• There is also work being done in my forks of Goattracker2 and GTUltra
