RP2040 Multi-effect Pedal - Mainboard V2.1
These are the files for the V2.1 mainboard. SMD components are compiled in the BOM for PCBA.
As it creates extra complexity by having these two board in the same project, please see my other projects for the daughterboard.
Separating them streamlines the review and production process for PCBWay.
This design revision uses the PCM3060 instead of individual ADC and DAC modules.
The design was tested on a similar layout and identical schematic, so it should work completely fine.
If you do not want to take any risk, I recommend creating the V1.2 revision instead.
THT parts, and connectors need to be soldered manually.
or the full list of components, see the ibom.html file in the repository on GitHub:
RP2040 Multi-effect Pedal - Mainboard V2.1
