This is the back plate for the pcb-based enclosure for Microdexed Touch.
This part is universal to use for BOTH pcb-based front panels, for the 2.8" and also for the 3.2" Display.
UPDATED 2025-01-10: Now also will fit the upcoming MDT version with on-board encoders
If you want a full covering bottom plate added below this part, you optionally can add this:
mdt_pcb_enclosure_optional_back_cover
Microdexed Homepage on pcbway:
https://www.pcbway.com/project/shareproject/MicroDexed_Capacitive_Touch_64970fee.html
Project Homepage:
https://codeberg.org/positionhigh/MicroDexed-touch
(with front panel, 2.8" Display)
(with front panel, 3.2" Display)
Above front/backplates are a (more simple) alternative solution to the SLA printed, full enclosure:
You find the SLA printed Enclosure on the bottom of the main page: https://www.pcbway.com/project/shareproject/MicroDexed_Capacitive_Touch_64970fee.html
mdt_pcb-enclosure-back
*PCBWay community is a sharing platform. We are not responsible for any design issues and parameter issues (board thickness, surface finish, etc.) you choose.
