Description

JoySticks DB9 to Header

DB9-to-header connectors designed for retro computer emulation projects, including systems such as the ZX Spectrum, Amstrad CPC, and Commodore 64. These connectors allow easy interfacing between classic DB9 joystick or peripheral ports and modern microcontroller platforms via standard 2.54 mm headers. Ideal for hobbyists and developers building custom adapters, emulator hardware, or restoration projects.

Download Gerbers Download BOM(Bill of materials)

Sep 01,2025

89 views

JoySticks DB9 to Header

2 Layers PCB 33 x 76.2 mm FR-4, 1.6 mm, 1, HASL with lead, Blue Solder Mask, White silkscreen

DB9-to-header connectors designed for retro computer emulation projects, including systems such as the ZX Spectrum, Amstrad CPC...
