Smart Home HMI with WiFi, Security and Sensor Interface
Check out for future updates.
New information (schematics, status firmware,..) will follow soon!!
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Updates:
2022-12-22 Short Christmas Update: PCBs arrived and built up by hand is finished. First testing software for hardware is written an tests are running. No issues till today and it seams to be a good running board without design failures... But test is not finished... After testing I will release a first demo firmware with general HMI functionality after christmas days.
So Christmas is coming and I wish everybody good days with family and friends.
2022-10-11: Gerber,BOM,Assemby and Systemdesign added
2022-10-09: first Gui pictures added
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
7 Inch variant with cap touch and 800x480 pixel
10.1 Inch variant with cap touch and 1024x600 pixel
Shown peripherie:
- I2C 5V with Expander Chip to drive 8 relays
- I2C 3V3 with RTC, HTU21, AHT20, Oled, ADS1115 ADC, and MLX90614 interface
- Fingerprint sensor GT511
- MFRC522 RFID
more Interfaces/peripheries :
- CAN Interface
- USB Interface
- 12V LED driver (3A)
- AQS Sensor GP2Y1010AU0F
- Livolo smart light switch
- 433Mhz RF Transceiver interface (USART)
- HCSR501 Interface
- ESP8266 WiFi Interface
No interface selection or multiple pin usage for named peripherie. So everything can be used at the same time.
Display Interface (created with TouchGFX)
First screenshots
I am trying to create a motion video next update( created with an earlier pcb project and will be the base for this project)
