Description
PSVSD Version 21
Yifanlu's PSVSD board design
Took me a while to figure out how to order a PCB properly so figured I'd share it so people can just click and go instead of figure out what all the fields do.
You can find the source files at https://github.com/yifanlu/psvsd, which are licensed under CC-BY.
Code
https://github.com/yifanlu/psvsd
Jul 18,2023
774 views
PSVSD Version 21
2 Layers PCB 33.2 x 30 mm FR-4, 1 mm, 1, HASL with lead, Blue Solder Mask, White silkscreen
Yifanlu's PSVSD board design
774
3
0
Published: Jul 18,2023
Standard PCB
Download Gerber file 18
BOM(Bill of materials)
Centroid file
PCBWay Donate 10% cost To Author
File Last Updated: 2023/08/22 (GMT+8)
File update record
2023-08-2217:55:09
Centroid file is updated.
Only PCB
PCB+Assembly
*PCBWay community is a sharing platform. We are not responsible for any design issues and parameter issues (board thickness, surface finish, etc.) you choose.
Under the
Attribution-ShareAlike (CC BY-SA)
License.
