OPA "Alice" Pencil Microphone

Based on Jules Rykebushs Dual OPA "Alice" Microphone Circuit - a PCB fitting in some pencil microphone bodies.

MXL 441, MXL 603S, Takstar CM-60, Pronomic SCM-1

You need an electret capsule, this PCB does not provide polarisation voltage what you likely need for a true condenser capsule.

Perfect capsule is a Primo EM-21.

Anyhow I had great results with this capsule (even though it is a true condenser) when used on high SPL sound sources like drums:

SDC Capsules – Microphone-Parts.com

Jules project:

Dual OPA "Alice" Microphone Circuit - Share Project - PCBWay

Download BOM(Bill of materials)
