Tools, APP Software Used etc.

	KiCad 8.0 KiCad
	FreeCad

Description

30 mm Cage Plate LED MCPCB.kicad_pcb

This board is an entirely self-contained LED and driver circuitry designed to be compatible with the Thorlabs 30 mm cage plate system: https://www.thorlabs.com/navigation.cfm?guide_id=2004

The LEDs on the board are closely spaced so that all four LEDs efficiently couple into a 5 mm liquid light guide or other optical paths.

The full project description can be found here: https://github.com/Llamero/30mm_cage_plate_LED_MCPCB

Download Gerbers Download BOM(Bill of materials)

Jul 17,2025

116 views

30 mm Cage Plate LED MCPCB.kicad_pcb

1 Layers PCB 40 x 40 mm Aluminum board, 1.6 mm, 1, HASL with lead, White Solder Mask, Black silkscreen

This board is a four LED board compatible with the Thorlabs 30 mm cage plate system.

116

Published: Jul 17,2025
