RFID Door Locking System
Fully tested Door Lock system. Works with an RFID-RC522 .
Works with an Arduino Nano board. It is standalone, once you upload the sketch..
First you will define a MASTER card, then, using the MASTER card, you can add or delete (UP TO 165) further TAGs.
I already mounted a lot of them, no problems found at all.
contact: grabador.laser@gmail.com.
Thank you !!
Aug 03,2021
1,509 views
RFID Door Locking System
2 Layers PCB 55.9 x 83.8 mm FR-4, 1.6 mm, 1, HASL with lead, Red Solder Mask, White silkscreen
Fully tested Door Lock system. For component details and sketch, contact: grabador.laser@gmail.com. I'll try to upload a detailed video soon
