monolith

DIY wireless data logging platform for Student Formula and Baja.

Features

📡 Full wireless support

• Real-time telemetry
• Download recorded data
• Transmit User Events
• Transmit CAN messages
• Configure device (e.g. CAN bit rate)

📀 10 Hz data rate with various signals

• 1x CAN 2.0(A/B)
• 1x External GPS
• 1x Internal 6-axis Accelerometer & Gyroscope
• 4x Digital input channels
• 6x Analog input channels
• 1x Power supply voltage sensor
• 1x Chip temperature sensor

💡 Customizable web-based data analysis tool

🍺 Fully Open-source & Open-hardware under the Beerware license

Preview

Web Control Hub for live telemetry, data viewer and device/ui configurations.

Documentation

Full documentation for DIY and usage details.

Others

The name of the project was inspired by Arthur C. Clark's novel `2001: A Space Odyssey`.

LICENSE

For non-commercial use only:

"THE BEERWARE LICENSE" (Revision 42): LUFT-AQUILA wrote this project. As long as you retain this notice, you can do whatever you want with this stuff. If we meet someday, and you think this stuff is worth it, you can buy me a beer in return.
