Tools, APP Software Used etc.

Proteus

Description

MegaWang 2000 Turbo Edition - 47 - Bitmap RGB layer

This video shows the bitmap RGB 565 layer working with the Commodore 64 and additional hardware. I'm working on finalising the manufacturing design for the remaining boards.

The main project page with dev logs and downloads: https://martin-piper.itch.io/bomb-jack-display-hardware

Github repository: https://github.com/martinpiper/C64Public/tree/master/VideoHardware#readme

Previous SDK demos: https://www.youtube.com/watch?v=p50d_DsQ8WY

This is part of a modular audio and video hardware for retro machines like the Commodore 64. Designed to use 74LS series TTL ICs available back in the 1980s/1990s, something you can solder at home from parts or order ready assembled.

Download Gerbers Download BOM(Bill of materials)

Oct 28,2025

283 views

MegaWang 2000 Turbo Edition - 47 - Bitmap RGB layer

6 Layers PCB 205.7 x 81.1 mm FR-4, 1.6 mm, 1, HASL with lead, Green Solder Mask, White silkscreen

This is part of a modular audio and video hardware for retro machines like the Commodore 64.

283

Published: Oct 28,2025

Standard PCB

Download Gerber file 1

BOM(Bill of materials)

Centroid file

Other files for Assembly
