Lurking for a simple digital filter for my modular synthesizer, I got aware of the existence of a library capable of turning any arduino board into a wavetable oscillator... WHAAAT!I could not resist (how could I! Korg DW8000 is still one of my favourite synthesizers!) and immediately started developing a pcb for an eurorack wavetable oscillator based on Mozzi library.In the following I will show you how I designed my voltage controlled wavetable oscillator prototype for modular systems.FeaturesI designed the board layout with very specific functions in mind, but given the possibility to upload any custom sketch/firmware, this can be seen as a base for a lot of different modulars (i.e. Mozzi oscillators, but not only that).In general the PCB is designed to handle:- up to 4 potentiometers, for direct control of parameters- up to 3 external control voltages (0-5V, overvoltage protected)- 1 trimmer for fine, permanent settings (i.e. V/oct scaling)- up to 7 digital pins configurable as inputs or outputs- small footprint- eurorack power supply ready (2x8 pins IDC connector)- built-in Midi IN circuit- open firmwareThe community around the Mozzi library made an incredible work in these years. Not only the libray itself is very deep, but there are also utilities that can help make this thing even more interesting. In example: what about the possibiliry to ?create your own wavetables from wav files! O_O'Hardware Design Choices and CircuitsUsing arduino and Mozzi library for this project makes the pure sound generation "simple", but some boundary/slave circuit are needed to accomodate an arduino into a module that will coexist with other, external modules.A necessary precaution concerns input voltages: Arduino sends and receives "logical" inputs, therefore it is limited to the 0-5 V dc range both in input and output. To overcome this, I have included three voltage limiting circuits, one for each analog inputs left for CVs. This circuit can be done in various ways: frequency divider, use of a Zener diode, use of Schottky diodes... just to cite the most common. The circuit adopted in this board is made with schottky diodes as per Doepfer specifications. The circuit lowers any voltage above 5V (in a modular system we can expect up to 10-12V for a control voltage), "stops" any negative voltage, and transfers variable voltages below the 5V threshold voltage.Another built-in circuit is MIDI input. The circuit is built around a common optocoupler (6N138) and it's shown above. To optimize the code, I generally prefer to use hardware serial instead of software serial. This project makes no exception. Being that the MIDI circuit interfere with arduino Rx pin even when nothing is connected, I placed a simple jumper, labelled "JRx". This has to be removed/switched every time you want to upload a new sketch and then inserted back in for MIDI to work. A little annoying, but keeping the code lean has priority in a project that deals with waves generation (you will get used at that, don't worry!).To use Mozzi library at its best, audio output is made compatible with both STANDARD PLUS and HIFI modes.In HIFI mode, bit depth is increased and effective noise floor reduced. It does not have an effect on distortion or unwanted PWM frequency interference, anyway.To have your hardware ready for HIFI mode, populate R1, R2, R3 and C1 with:R0 - 1M ohmR1 - 1M ohmR2 - 3.9K ohmC1 - 4.7nFTo have your hardware ready for STANDARD PLUS mode, instead, populate R2 with a 330 ohm resistor and leave the other components unpopulated.Setting HIFI mode asks for both the described components in the output stage, but also for a software mod. Go to "Documents\Arduino\libraries\Mozzi-master", open "mozzi_config.h" and change#define AUDIO_MODE STANDARD//#define AUDIO_MODE HIFIto//#define AUDIO_MODE STANDARD#define AUDIO_MODE HIFIIn this shield, all arduino nano analog inputs are wired: four are dedicated to the front panel potentiometers, three can be used for external analog inputs (with overvoltage protection) and the latest (A7) is hard-wired to an utility trimmer.A total of seven digital inputs are accessible for user functions.Please notice that the sketch I wrote cannot be uploaded into an Arduino nano with ATmega168 processor because of memory limits. Be sure to buy a nano with ATmega328P.Even if the board is equipped with a full 8x2 IDC connector, being 100% digital this projects is powered by +5V only.The SketchI wrote a sketch as a starting point for future implementations and features.Being this intended to be the oscillator of a modular synthesizer (mine :) ), you will not find a whole synth coded, but a steady, two waves generator.So, what I coded here are two detunable, wavetable assignable, pure oscillators. Selectable waves are sine, triangular, saw, square, and white noise, in any combination.The oscillator pitch can be controlled by MIDI or voltage.In the followings the functions of potentiometers, buttons and incoming MIDI messages.PotentiometersThe first potentiometer POT_A0 controls the relative detuning of wave two.The second potentiometer (POT_A1) acts on the relative gain of the two waves: fully clockwise you will hear wave one only, fully counter-clockwise wave two only. Any other position results in a relative blend of the two waves.The third potentiometer (POT_A2) controls the global output gain.The fourth potentiometer (POT_A3) affects the main tuning.The built-in trimmer is used for V/oct scaling.MIDIIf a MIDI note-on messages is received, waves are tuned accordingly.A gate out signal is output at D8 pin when a MIDI note-on (HIGH) or note-off (LOW) message is received, accordingly.Default MIDI channel is set to 1 and can be easily changed by uploading a new firmware.Both MIDI note-on and pitchbend are supported.MIDI note priority is set to latest. It is possible to code other note priorities (lowest, highest) but the actual code does not support them.Control VoltagesThis wavetable oscillator is not MIDI-only, but also voltage controlled. By sending a 0 - 5V signal to analog input A6 both waves will tune accordingly. As said, the trimpot acts on V/oct scaling.A simple voltage control over wave two detuning is coded: if a reading other than 5V is available at analog input "A4", it is summed to POT_A0 reading and toghether detune the oscillator.MIDI note-on message has the priority over voltage pitch control, and disables it. In order to re-activate CV pitch control, disconnect the MIDI cable then reset the microcontroller.Please notice that I had not the possibility to test adeguately the CV part of the code (I have not a keyboard, nor a controller adopting the V/Oct standard at the moment), but I will in the near future.ButtonsTwo non-latching buttons are used to indipendently select wavetables on the fly. Wavetable one can be changed by pressing a normally open button/switch shorting D2 to ground; wavetable two with a button on D3. You cycle through waves at every button press. Waves are sine, triangular, saw, square and white noise in any combination, but they can be easily changed modifying the sketch.Two non latching buttons connected to D4 and D5 are used to set the pitch height of each wave. You can transpose the base pitch up two octaves and down one octave.The full code can be found HERE (Github).Please notice that I have left some code lines for functions I planned and implemented, but in the end I have disabled. In example, I had planned some sort of modulation for at least one of the two waves (vibrato) to give some additional movement to the base sound. It's disabled, but still there for future reference :)BOMThe board is intended to be mounted perpendicular to the front panel. If your case is not deep enought, you can lock the board on the case bottom and use wires to gain electrical connection with elements (potentiometers, buttons, jacks and so on) on the front panel.All components values are silkscreened on the PCB to make assembly easier.Follows the list of components:Microcontrollers- 1x Arduino nano (ATmega 328p, NOT ATmega168p)Capacitors- 1x 100n ceramic- 1x 4.7n ceramicResistors, Potentiometers, Trimmers- 4x 10K ohm potentiometer- 1x 10k ohm trimmer- 5x 1000 ohm resistor- 1x 200 ohm resistor- 1x 330 ohm resistor- 2x 1M metal film resistor (HIFI mode)- 1x 3900 metal film ohm (HIFI mode)- 1x 330 ohm (standard_plus mode)Diodes and optocouplers- 1x 6N138- 6x BAT42 Schottky- 1x 1N4148 Others- 1x DIN5 MIDI connector- 1x 2x8 IDC connector- 1x PCB switchFuture Plans - Paraphony!Realizing a single, two waves oscillator was incredibly fun. When I start thinking at what could be next, I cannot stop to figure that a polifonic chain of such wavetable oscillators would be awesome... one of the next projects could well be a midi controller for a stack* of wavetable oscillators like this, or eventually for any CV oscillator!* stack reasonably could mean four: I have these MCP4728 4 channels DACs on their way to me ... ;)
