Description

iSpindel The Jeffrey 2.69 - Open Source Distilling

The Jeffrey 2.69 PCB for the iSpindel. Please head over to www.OpenSourceDistilling.com/iSpindel for an in-depth description, parts list, schematic, assembly instructions, and video tutorials.

The development history of The Jeffrey PCB can be found by clicking here.

The changes from The Jeffery 2.1 to The Jeffery 2.69 are:

1 - Oversized solder pads have been added. A large pad in the middle and two smaller pads on the sides. The middle pad should provide more than enough real estate to add solder to balance and offset calibrated iSpindel to 25 degrees in pure water.

2 - The temperature probe has been rotated 180 degrees so the rounded part of the probe lines up with the curved interior wall of the petling.

Code

https://github.com/OpenSourceDistilling/The_Jeffrey_PCB

Schematic and Layout

https://www.OpenSourceDistilling.com/iSpindel

Jan 08,2021

30,239 views

iSpindel The Jeffrey 2.69 - Open Source Distilling

iSpindel PCB with movable surface mounted battery holder. Keep track of your fermentation with a wifi electronic hydrometer.
