Components
|
SST39SF040-55-4C-NHE-TMicrochip Technology
|
x 1 | |
|
1206 100nf capacitor |
x 1 |
Description
32kb flashcard for nintendo game boy , small pcb version
same functionality as the other 32kb flashcard , but on a very small pcb
''a 32kb flashcard for nintendo gamer boy , rom only type , ideal for small homebrew ( no mapper , no save feature : ROM ONLY type )
you can flash it with gbxcart rw from insidegadget
need a 100uf capacitor 1206 smd
somes chips are compatibles with the pcb :
AT49F040:
AT49F001T:
SST39SF010A:
SST39SF020A:
SST39SF040:
SST39SF010A:
SST39SF020A:
SST39SF040:
SST39LF010:
SST39VF010:
all in plcc32 form factor
i personally use sst39sf040
need order it in enig and 0.8mm thickness , 3th picture is a functionnal prototype
