Description
TDA 7265 Amplifier For Active Refference Monitor Speaker
The circuit use TDA7265 as the power amplifier. This IC can produce good flat frequency response and it best for use on active refference speaker.
For the preamp I use LM4562NA IC.
I design this project suitable for audio editing, recording, and other audio works.
The circuit is made as simple as possible with standart through hole Components that easy found on the store.
It powered by symmetrical transformer 18-0-18/3A
More : Barlex Respectaizer Youtube Channel
Schematic and Layout
https://youtu.be/1rnUlGO-ICY
Jul 23,2020
2,821 views
TDA 7265 Amplifier For Active Refference Monitor Speaker
The circuit use TDA7265 as the power amplifier. This IC can produce good flat frequency response and it best for use on active spk
2821
4
0
Published: Jul 23,2020
Standard PCB
PCBWay Donate 10% cost To Author
Only PCB
*PCBWay community is a sharing platform. We are not responsible for any design issues and parameter issues (board thickness, surface finish, etc.) you choose.
Under the
Attribution-ShareAlike (CC BY-SA)
License.
