ZX Max 128 Issue 5
This is a ZX Spectrum 128 Clone base on CLPD EPM7128S. The ULA implement is base on "ULA chip for ZX Spectrum" project by Rodriguez Jodar, Miguel Angel (https://opencores.org/projects/zx_ula)
PCB is half size of original ZX Spectrum, can be fit in 48K or 48K+ case.
- PCB version 5,
- 32K ROM (27C256) and 128K RAM
- 2 x AY-3-8910 sound chip (Turbo Sound)
- SAA1099 sound chip
- SAM2695 MiDi Player
- DivMMC on board
- Kempston Joystick Interface
- Composite and RGB PAL output
Code
Project Repository
https://github.com/DonSuperfo/ZX-Max-128
