Superfo Harlequin 128 Issue 4B
Superfo Harlequin 128 Issue 4B
This is a ZX Specrum Clone base on Harlequin by Chris Smith (http://www.zxdesign.info/harlequin.shtml). PCB is the same size as original ZX Spectrum, can be fit in 48K or 48K+ case.
PCB current version is 4B, support 48K, 128K, 128K +2A/+3/+3E ROM
Support ALL RAM mode, you can run CP/M with this board when using with floppy disk interface
Flash ROM 29F040/39SF040 (upto 8 banks of 64K, select by dip switch)
Video signal is ZX Spectrum 48K/128K timing (select by switch)
AY-3-8910 sound chip
Kempston Joystick port
RS232 on board (option)
Composite output, support both PAL and NTSC (There is a footprint to install 3.579MHz oscilator for NTSC)
Fix AY address for some Russia Games
Use standard ZX Spectrum Adapter, 9V with center pin negative (-
Superfo Harlequin 128 Issue 4B
