Description
NucleoShield
This PCB is a shield for STM32 Nucleo with conectors for 6 IR sensors, encoders, UART, and 2 stepper motor drivers. It also has a connectors for vacuum pumps and 2 for pneumatic valves. It is used in manufacturing autonomous robot.
Schematic and Layout
nucleoshield.kicad_sch
Feb 20,2025
341 views
NucleoShield
2 Layers PCB 121.5 x 100.3 mm FR-4, 1.6 mm, 1, HASL with lead, Green Solder Mask, White silkscreen
Nucleo shield with connectors for sensors, encoders, lcd 16x2 display, 2 stepper motor driver and a lot more.
341
0
0
Published: Feb 20,2025
Standard PCB
Download Gerber file 5
BOM(Bill of materials)
PCBWay Donate 10% cost To Author
File Last Updated: 2025/02/22 (GMT+8)
File update record
2025-02-2218:42:50
Gerber file is updated.
2025-02-2102:42:38
Gerber file is updated.
Only PCB
PCB+Assembly
*PCBWay community is a sharing platform. We are not responsible for any design issues and parameter issues (board thickness, surface finish, etc.) you choose.
Under the
Attribution-ShareAlike (CC BY-SA)
License.
