Description

Arduino UNO Microcontroller Card - (MCU: ATmega328P-PU) - (USB-TTL CH340G)

Card Dimensions: 85x65mm

Mounting Hole Dimensions: 55x55mm (M3.5)

PCBWAY GERBER VIEWER

USB-TTL CH340G
MCU- ATmega328P-PU
DC Output for 5V- 800mA
DC Output for 3.3V- 100mA
DC In 7-12V

It is a microcontroller board that can be programmed with USB, with its small size and low cost.

You can leave a message for your questions.

Have a nice day everyone <3

https://www.youtube.com/channel/UC7kKzcRrEQOwR5MZzJxQeig

-----Also, if you click on the link below and create an account, you will earn a 5$ coupon.

-----https://www.pcbway.com/setinvite.aspx?inviteid=428195

Dec 31,2020

6,557 views

Arduino UNO Microcontroller Card - (MCU: ATmega328P-PU) - (USB-TTL CH340G)

Atmega328p based microcontroller board. It has more power input and output than arduino uno boards.
