Components

	2x20 Pin 40 Pin header female	x 1
	S3B-XH-A JST	x 5

Description

Diecast Remote Raceway - Connector Breakout Board HAT

Raspberry PI pass-through HAT for the Diecast Remote Raceway Starting Gate. This PCB contains a 2x20 pin GPIO header and five JST XH 3 pin right angle connectors. It connects the Servo and up to four lane sensors to the Raspberry Pi Zero. The complete project is detailed on the GitHub page:

https://github.com/tquiggle/Diecast-Remote-Raceway/

Download Gerbers

Aug 23,2026

41 views

Diecast Remote Raceway - Connector Breakout Board HAT

2 Layers PCB 30 x 65 mm FR-4, 1.6 mm, 1, HASL lead free, Green Solder Mask, White silkscreen

Connector Breakout Board for Diecast Remote Raceway project: https://github.com/tquiggle/Diecast-Remote-Raceway/tree/master/StartingGate

Published: Aug 23,2026
