Description

BlueSCSI 1.1-a 50 Pin

BlueSCSI is an open, cheap, and easy to use SD SCSI solution for vintage computers.

BlueSCSI provides a convenient way to use MicroSD cards hard drives in your Vintage Macintosh or workstation.

Simple Design – Place a file on an SD card and go. Nothing to configure or setup.

Power Options – In most cases it is powered directly from the SCSI bus. If your bus can’t supply enough power it provides a berg power connector or via USB.

Performance – Up to 1024KB/sec Read, 912KB/sec write.

Compatibility – Most Macintosh machines that use SCSI – Check out the Wiki page at https://github.com/erichelgeson/BlueSCSI/wiki/Supported-Systems for a full list

Full up to date assembly instructions for this can be found on our wiki page.

https://github.com/erichelgeson/BlueSCSI/wiki/BlueSCSI-1.1-Desktop-Assembly

BlueSCSI is distributed under a non-commercial license for personal use.

Code

Source

https://github.com/erichelgeson/bluescsi

CAD-Custom parts and enclosures

Cases

https://github.com/erichelgeson/BlueSCSI/tree/main/3D-Files/1.1

Download Gerbers Download BOM(Bill of materials)

Mar 06,2022

8,384 views

BlueSCSI 1.1-a 50 Pin

BlueSCSI allows you to emulate up to seven SCSI-1 devices from an SD card. Easy to build yourself! Non-commercial - personal use only.

8384

22

7

10.00 (3)

Published: Mar 06,2022

Standard PCB

Download Gerber file 118

BOM(Bill of materials)

Purchase

Donation Received ($)

PCBWay Donate 10% cost To Author

File Last Updated: 2023/12/22 (GMT+8)

File update record

2023-12-2210:37:06

Parts List (BOM) is updated.

Only PCB
