4 Ohm Woofer 2nd Order low pass Crossover@500Hz
A low pass@500Hz 2nd order Crossover for a 4 ohm woofer:
Series inductor:
L=0.25 mH
Shunt capacitor:
C=4.0 μF
May 08,2026
9 views
4 Ohm Woofer 2nd Order low pass Crossover@500Hz
A simple In line passive crossover to push the limits of your Woofer with clear bas.
