PSVSD 2.1 - SDCard adpater for the PS Vita
This is the PSVSD 2.1 board by Yifanlu. It allows the 3G modem to be replaced with an SDCard (Jailbroken systems only).
The files have been unmodified other than converting it to Gerber.
Please see the original license file here:
https://github.com/yifanlu/psvsd/blob/master/LICENSE.txt
I used the following settings when ordering these myself, and the boards worked nicely:
Thickness : 1.2 mm
Min Track/Spacing : 6/6mil
Min Hole Size : 0.3mm ↑
Gold fingers : No
Surface Finish : HASL with lead
"HASL" to "ENIG" : No
Via Process : Tenting vias
Finished Copper :1 oz Cu
