GPU Power Cable to 12x SATA Power Cable Adapter Board
This is the shared project for the Gerber files for a small PCB that allows you to take either a 6-pin or 8-pin PCIe power cable from a PC power supply and turn it into 12 SATA power connectors for a bunch of hard drives! This is designed to solve the issue of there being very few PC power supplies on the market with tons of SATA power connectors on them for DIY storage server builds, and this board also helps solve the issue of using SATA power splitters that have proven to be a bit of a fire hazard in the past.
Looking for more info on this project and detailed instructions on how to build it? Check out my YouTube video on it!
GPU Power Cable to 12x SATA Power Cable Adapter Board
*PCBWay community is a sharing platform. We are not responsible for any design issues and parameter issues (board thickness, surface finish, etc.) you choose.
