Commodore 128 Internal Pi1541 Interface

2 Layers PCB 36.2 x 33 mm FR-4, 1.6 mm, 1, HASL with lead, Black Solder Mask, White silkscreen
Interface that connects to the internal IEC pin header on the C128 and a Raspi3b+ or Zero2W to work as a 1541 or 1581 drive emulator.
