Components
Tools, APP Software Used etc.
|
OrCad Cadance |
Description
Amiga DFO and External Floppy Swapper v2.1
This module can swap an internal DF0: drive with an external DF1: floppy drive in order to boot from an external device, such as a Gotek Floppy Emulator.
First module fits under the MOS 8520 Even CIA.
Second module is inline with the internal DF0: drive.
A small CPU detects two fast consecutive resets (CTRL-A-A twice). This will activate or deactivate the floppy swapping.
A piezo will emit sounds when the swapping is activated or deactivated.
This device will fully support external booting from any 880K disks, while still permitting the use of internal DF0: as DF1: (hardware fix)
Apr 13,2023
1,080 views
Amiga DFO and External Floppy Swapper v2.1
This module can fully swap an internal DF0: drive with an external DF1: floppy drive in order to boot from the external device.
