MAX232ECWE+Analog Devices / Maxim Integrated
|
x 1 |
|
EagleAutodesk
|
TI99 Texas Instrumens and Commodore Wiffi Modems
Modem for Commodore 64 and compatible. It also serves to connect to the classic Ti99 (PEB). On Commodore you can connect at 56700 bps and on TI99 at 1200 bps. Configuring module Lolin v3
When you connect to your TI99 you will have to power it externally in Lolin v3. Not necessary on Commodore
The firmware boots at 1200 bps. In realterm windows use ATB57600&W to use in retroterm turbo56k
For use only with commodore no max232 or capacitors needed
NOTE: in the video a 1x12 edge connector is used, it does not have 5v connected. use external source
https://www.youtube.com/watch?v=id-0-a5xMgQ
TI99 Texas Instrumens and Commodore Wiffi Modems
