We ordered a standard 4-layer PCB for our ZETACAP project, panelized with two boards per panel and manufactured with a HASL finish. The overall quality is very good, with clean solder mask application...
For our DANENC15 project, we ordered a 4-layer PCB with four boards per panel and a standard HASL surface finish. The manufacturing result is excellent, with precise dimensions, clean board edges, goo...
We ordered a classic double-sided PCB with through-hole technology only, without any SMD components, and the result was excellent. Even for a relatively simple and traditional design, PCBWay maintaine...
We ordered a PCB without copper, intended to be used as a front panel, with focus on solder mask color and silkscreen quality. The result is very satisfying: the solder mask is uniform and consistent,...
We ordered a 4-layer PCB panel that required a more advanced setup compared to our previous projects. The PCBWay engineers followed our request to reproduce the same panel layout used in an earlier de...
We ordered a 1 mm PCB without copper, featuring only green solder mask and silkscreen. The boards were milled individually, not panelized, and the contouring was perfectly executed. The green finish i...
two simple double sided PCBs. it was interesting to use the common shipping service for two different projects. this time too the chat service was fast and efficient! first time also, that I make the ...
We ordered a 1 mm PCB without copper, designed to be used as a front panel rather than as an electrical circuit. The solder mask color is uniform and consistent across the entire surface, while the si...
This project was another traditional double-layer PCB using only through-hole components, a technology that may be considered “old school” today but still requires precision and attention during manuf...
We ordered another PCB intended as a front panel, without any copper layers, using white solder mask and black silkscreen. The visual appearance is excellent: the white finish is uniform and clean, wh...
We ordered a 4-layer PCB with a relatively advanced design, including BGA components and a precisely milled board outline. The manufacturing quality is excellent, especially considering the fine pitch...
We ordered a 1 mm PCB with no copper layer, only blue solder mask and silkscreen. Each board was individually milled, with excellent edge quality and precise dimensions. The blue color is vivid and co...
New project! This time, due to an error (of my company's design) I was forced to make this small PCB to rotate a footprint 180°. I hope to be able to deliver on time to my customer, although I will do...
This PCB has no copper tracks, it is just a cover for our box that contains our "real" electronic board, an industrial input-output module with EtherCAT communication bus. Unfortunately, despite the v...
