    Product Description

    4.3-inch capacitive touch LCD screen (STM-32)

    Product parameter：

    Type of interface: LCD: lntel8080-16-bit parallel port | touch screen: IIC

    Color format: RGB565

    Color depth: 16 bits

    LCD driver chip: NT35510

    Capacitive touch chip: GT968/GT1151

    LCD resolution: 800*480

    Touch screen type: capacitive touch

    Touch points: touch at 5 points at the same time

    Output rate of coordinates: 75Hz

    Screen size: 4.3 inches

    Working temperature: -20℃~70℃

    Storage temperature: -30℃~80℃


    Product features：

    • The screen resolution of the module is 800 * 480, with 16-bit true color display
    • Self-contained driver, no additional driver, single chip microcomputer directly used
    • Faster speed, theoretically, the screen speed can reach 78.9 frames/second
    • Capacitive touch screen is used to support 5-point simultaneous touch control
    • On-board backlight circuit only needs 3.3V&5V power supply, without external high voltage
    • Simple interface (LCD adopts 16-bit 8080 parallel port, touch screen adopts IIC interface)
    • Processing with brand-new components, pure copper gold-plated needles
    • Excellent PCB materials, gold deposition process, stable and reliable
    • Humanized design, each interface is marked with silk screen, which can be used at a glance
    • PCB size is 62.25mm*117.5mm with mounting holes
