Hello friends, in this blog I want to talk about a project that I have been developing in recent monthsIt is a pure sine wave inverter from the egs002 module with SPWM, this inverter can work from 12V to 48V with powers ranging from 600W to 12V up to 2400W at 48V, this power is RMS, the peak power of the inverter would be roughly twice the RMS power.That is, we will have approximately a power of 1200W at 12V and 4800W at 48V, this inverter works through an H bridge which connects the positive or negative at high frequency to generate a PWM wave with positive and negative peaks that finally through of a capacitor and a coil will smooth these pulses and it will become in a few words a sine wave.To obtain this power we must use mosfets of approximately 120 amps or more for each one, so that they can withstand the current peaks that is natural in high frequency and that it can work for long times, I also want to make special emphasis on the issue of cooling of this inverter since as many will know the temperature in the mosfets it is vitally important to know how much current they can conduct without causing damage, so it is very important to use a generous heatsink and if possible with active cooling.Having a good bank of capacitors is essential for the implementation of this class of inverters since they will prevent the high current peaks generated by the inverter from being assumed by the batteries that, if they are very small or of little capacity, will suffer shortening their useful life and also causing instabilities in the input voltage and therefore in the output voltage as well.To finish, I want to warn about the precautions that must be taken to put the project into operation and to obtain the desired power, mainly I would like to emphasize the cables to be used since we are working relatively at low voltage in the batteries, depending on the power that We will need to be circulating 40 amps or much more, that if the cable is very thin or is not of the necessary gauge it will overheat and can even burn, so you have to be very careful with it, on the other hand install a fuse or some type of safety switch for any unforeseen event is always very helpful and safe for our projects, especially if they have a lot of power, thank you very much for your attention.

we have developed this print for our non-profit organization that makes it possible to talk to a walkie-talkie all over the world we are expanding our services every day and currently we already have members in the Netherlands, Germany, Belgium and want these continue to expand the service on the basis of sponsors.Handyman* aims to connect analog and digital communication in an open domain and to raise radio communication to a higher level using existing and new techniques. This is how we keep this hobby alive and current.Activities take place on a non-profit basis.We do not charge a fee for the use of our website and it is accessible to everyone. We also build svxlink Raspberry repeaters and need support for this.

I'm working to make an automatic on/off system of the water pump for a relative who's been having a ton of issues with this as they have to manually turn the motor on/off. They're aged hence the further motivation.I'll be utilizing the NC555 IC to be the brains of this operation. The concept is very simple and requires a few wires in the upper-level tank and underground tank that are used for detecting the water level.The circuit basically turns on the water pump (using a relay) when the underground tank's water level is adequate and upper tank has room for water. If the upper-level water tank doesn't have room for more water or if the underground tank doesn't have enough water, the water pump remains off.I've already made using the traditional method, however since there's a 220V AC input, it's not safe to be used by someone inexperienced.I'm a student currently taking a gap year and plans to pursue Mechatronics engineering and further automate things like those that are otherwise manually done in my city.

This is a DIY handheld gamepad, made using ESP32 microcontroller. You might have seen such game controllers before. But most of them use Arduino. Or more specifically Arduino pro micro or Leonardo board. Because these boards support HID, or human interface devices over USB. but esp32 doesn’t have such feature. So how do we do it? Well, esp32 does have BLE, or Bluetooth low energy, which we can use to communicate wirelessly, over Bluetooth.So we have ESP32 module, as the central controller, then we have the USB type-C port, and a 3.3v regulator to convert 5v to 3.3v. Then we have the programming circuit, using ch340c usb to serial converter with auto programming mode and auto reset circuitry using duel transistors. We also have a battery charging circuit, along with overcharge, and over discharge protection. Which then boost up to 5v, using the boost converter ic. Next we have the joysticks, D-Pad buttons, trigger buttons, Neopixel LEDs, i2c port. And finally a 3way switch, to toggle between USB power and battery power.The gamepad has2 analog joysticks2 trigger buttons2 D-Pads6 addressable RGB LEDsand a i2c portIt can run using 2 18650 Li ion cells, which can be changed using the USB type-C port. And it can also be used to program the microcontroller. The design is inspired by the new ps5 controller, to give it a better look. The GPIO4 is connected to the battery using a voltage divider. So that we can measure the battery voltage. the NeoPixel LEDs will indicates if the controller is connected to a device or battery voltage is low.The code is based on BLE Gamepad library by lemmingDev. In the code I have defined all the GPIO pins for different inputs. Then in the setup there are some initial led animations. And as soon as the board is connected to the device, all LEDs will turn Green. And it will check battery voltage, in a time interval, which is defined earlier. Then we get the button states, and set the gamepad buttons accordingly. Then we take the analog inputs, and map it to suitable values. And finally set the axis according to the values we received. After uploading the code open Bluetooth menu on your Smartphone or PC and you will see a new device pops up. click on that to connect it and you are ready to play.

Greetings colleagues, my name is Johan and today I want to tell you about my project which is a 2kW MPPT solar charger with a maximum charging current of 40AThis charger was designed from the STM32F103C8 microcontroller since due to the complexity of the MPPT algorithm a good handheld processing speed with good precision ADC was needed, the power stage of this MPPT is designed from a synchronous source using mosfets common N channel as they are available anywhere in addition to their low cost and the great power they can handle.The efficiency of this charger if a common source with a diode had been used was around 80%, while with the implementation of a synchronous source this would be around 97%, crazy :). At this point I have to talk about power mosfets, the ideal mosfets to use in this charger are those that have a minimum resistance and that can withstand a current of no less than 130 A each, this because although the source It is very efficient, there will always be a loss in heat that must be dissipated, which causes an increase in temperature, greatly reducing the conduction capacity of the mosfets and ultimately damaging the charger, it is for this reason that the most robust mosfets should be used. possible and with the lowest internal resistance.I would also like to talk about the necessary inductor for this source since it is very important to take into account its saturation current, since we are talking about around 40A! that they will have to pass forces through the inductor and that it must withstand without saturating it and without changing its nominal inductance value.The fact of using SMD components in this design is because the through components tend to have unwanted components such as parasitic resistors in the capacitor, which in high frequency designs such as this charger can cause deviations in the calculations made for this source, that is why The use of SMD components in addition to making a more compact board design possible, improves the performance of the circuit.For this design he decided to use the IR2110 mosfet driver since it has a high switching speed in addition to a good current of up to 2.5 amps to turn the mosfets on and off, which makes it possible to turn on almost any type of mosfets without major complications and it is achieved practically anywhere.To measure the charging current of the battery, I decided to use a resistance (shunt) to measure through the voltage drop in it, by OHM law clear the current that is passing through it, I decided to do it this way Since we will have currents of up to 40A, it makes it difficult to get a hall-effect current meter that allows us to measure that current.At this point I say goodbye and send greetings to all the colleagues on the platform who in one way or another guided me to develop this renewable energy project, thank you.

This Arduino Uno is the same form factor as the original Arduino Uno, but is made to be solderable and cost-effective for education. The design costs less than $15 per board. All of the parts are either through-hole or large package surface mount, with the exception of the Atmel ATMEGA16u2, which is a VQFN. The ATMEGA16u2 will be pre-soldered before the seminar.I designed this board to teach soldering to Freshman and Sophomore engineering students at Cleveland State University about soldering and PCB design. I will be teaching 100 students over two weekends how to solder a PCB in hopes to inspire students to work on projects outside of class.The course will begin by going over the basics of what a PCB is and how they are made. We will then briefly discuss how this board was designed in Eagle and how to design and order a PCB for your own projects. My hope is that in the future, I will be able to start an elective course completely dedicated to teaching students how to design their own PCBs and then order them from places like PCBWay. We will then move to a brief discussion of soldering and how it works. Each of the 20 students will receive a soldering iron, a VikeDuino PCB, a USB-B Cable, and all of the components necessary to build the board. Using a microscope attached to a projector, I will demonstrate part by part how to assemble the board and how to solder. Once soldering is complete, we will load the bootloader to their board and upload a sample program. We will then program the boards with a test script___ and hook up a test circuit to the Arduino to verify that each pin works.After the class is complete, each student will have soldered his or her very own Arduino Uno and will get to keep the board for no cost. This will give every student the opportunity to work on Arduino projects outside of class, without having to purchase an Arduino for themselves.The Gerber Files for the PCB can be found on my Github: https://github.com/RowdyRutabaga/VikeDuino_Uno

This project RFID Door Lock System is beneficial in places where the door needs to be locked and opened a lot of times, so we just need to tap a card to lock and unlock it, which makes it very easy to use. I decided to make it for my project, so that it be beneficial for the school as well. It works using the RFID Module for arduino, in which when the card is placed, it sends the signal to servo motor using arduino, which moves the lock back and forth. This project can be used in places where only authorized personnel are allowed, as they can be given the RFID card to unlock and lock it. I (Saksham Khurana) a student from INDIA, would like to avail the sponsorship facility to make this project so that it can be used by more and more people.Material Required:- > Arduino nano> Lcd 16*2> servo motor> RFID module> PCB> latch> Transistors> Buttonif i would receive the sponsorship from PCBWay then i would ask all my friends and fellow mates to make PCB purchases from your company.Thanks and RegardsSaksham Khurana

Hello.After autumn, the new year and Christmas will come, and I decided to design a Christmas tree. Usually such Christmas trees are made on microcontrollers and LEDs. But in our difficult time, in the conditions of a worldwide pandemic, the prices of microcontrollers have risen sharply and many radio amateurs can not afford to buy them. I decided to make a Christmas decoration without using a microcontroller at all.At the heart of the Christmas tree, in addition to Christmas snowflakes and all sorts of such things, RGB LEDs with a built-in control circuit, you just need to supply power and they will shimmer in different colors, and how exactly depends on the diodes themselves. The fact is that there are LEDs with a slow overflow, and there are also fast ones, you can buy them in ChinaSo, these LEDs are operational from about 2.5 V to 4.5 V, I decided to put a penny stabilizer at 3.3 V and thus it became possible to power the Christmas tree from USB 5V.In the 1st photo, the Top Layer is presented - it is also the front view, the soldering mask for this layer is not used at all, and in the 2nd photo, the Bottom Layer will have a green soldering mask on it, but there will be small rectangular indents in them where there will be LEDs, there will also be no soldering mask.Why exactly is this so? I spied the idea on one of the foreign sites. The LEDs will be soldered on the contrary, that is, from the reverse side they will shine on the lumen of the textolite to the front side. The LEDs themselves are very bright and dazzle the eyes, and I decided to do just that. In any case, they can be soldered as shown in this publication, in general, there is a field for experiments.PCBWay always supports electronic engineers with creative projects, so I ask for sponsorship for the implementation of this project.

This project is a machine that enables you to control and of your electronic gadget using your mobile phone and google assistant. It can turn on and off anything that is connected to it. Material Required:Nodemcu (ESP 32 or ESP 8266) - 1830 point solderless breadboard - 2 or 1 PCBRelay Module - 1Jumper Wires - 5Rechargeable Battery - 1Micro USB Cable - 1I decided to make it because, I like making new different projects that are useful for the people.It works on the Wi-Fi which enables it to receive signals from the mobile phone.If I have connected by Home Light to this system and the Nodemcu is connected to the Wi-Fi, then I can turn it on and off from anywhere in the world unless the mobile phone is connected to some type of internet connection so that it is able to connected to the cloud and send signals.I want sponsorship for my projects so that I get encouragement and move ahead and make many more projects.If I get sponsored by PCBWay then I would recommend all my friends and classmates to by some or the other thing from your company.Thanks and Regards Saksham Khurana

PCBWay, hello.I want to make a project of a beautiful and original Christmas tree. The outline of the Christmas tree consists of 5 patterned parts. The basis of the Christmas tree is 16 address RGB LEDs WS2812B. An 8-bit STM8S103F3P6 microcontroller will control them and create a variety of effects. There is a button in the project, it can be used for various purposes, for example, you can switch effects or change the speed of effects or other functions.Structurally, the Christmas tree is made on a 2-layer printed circuit board.This is top layer:This is bottom layer:The dimensions of the Christmas tree do not exceed 10x10 centimeters. The Christmas tree has graphic elements on the theme of Christmas and new year. Also, for an additional pattern, asterisks are used on the same line with LEDs, this gives a special charm to the project.Thanks to the use of RGB LEDs, you can get practically all shades of colors, including transfusion from one color to another, as well as rainbow effects. It should look great.For example, a charger from a cell phone with 5V and a load current of 1A is suitable for power supply. As an alternative power source, you can use the computer's USB port or portable power bank.Such a project is perfect for both home use, and for work in the office or other areas of application, for example, it can decorate the interior in a restaurant or cafe. In addition, everyone will be able to repeat this simple and inexpensive project and order excellent quality printed circuit boards from PCBWay. In the conditions of a crisis and a worldwide pandemic, we electronics engineers and home-made people will be able to make our world a little brighter with the help of LEDs and a soldering iron.But, for the implementation of the Xmas Tree project, i need your sponsorship. Sincerely, Ivan.

My name is Sandipratama, i'm a keyboardist who interest in music producing and tech.This PCB project called "DAKON" in javanese it's mean traditional children's game. In this project i build mechanical keyboard with ortholinier or grid layout as normal keyboard and midi controller software because with the grid layout it's much more convenient for making beat like 4x4 drumpad, MIDI CC sender, macro shortcut, or just ordinary keyboard with grid layout.This design decide because the popularity of mechanical keyboard enthusiast has been increased about few years ago. I using Arduino Promicro 32u4 in this project which is capable enough to handle what i need of course and programming flexibility with ArduinoIDE or QMKfirmware builder if it's just for programing keyboard. But nowdays most of mechanical keyboard enthusiast identified mechanical keyboard just a hardware with fancy features that can be modified with pricey parts like switch, case and keycaps just for their prestige without knowing the actual capability.This design used basic 4x12 matrix keyboard wiring, and my plan using ArduinoIDE as base programmer. At the first plan i want to add Hardware Serial port with TX pinout via 3.5mm audio jack for for external midi controller purpose but i run out arduino pinout, so i just add some fancy features like RGB underglow and piezo buzzer breakout.I also had prototype with similliar purpose but just mini version with so much features like MIDI OUT port, RGB led, potentiometer support and encoder support.Thx to PCBway this mini version has been realized and work so fine for midi controller purpose and macropad.Now it's the right time to expand the mini version with bigger one !So many thank's to PCBWay for supporting hobbyist all over the world !

It was designed as a development board for young developers.And it is designed for high school and middle school students to improve their skills.This is actually also a keychain. Football is a very popular sport in our country, and this symbol is the emblem of a very popular club in the Turkish league, this club name ise Beşiktaş. Our aim here is to make our students love electronics by taking advantage of the popularity of football. The components we use are suitable for every student, as they are both easy-to-find and inexpensive materials.On our circuit, there are leds that light up one by one, respectively, and there are two bright leds that act as flashlights in the dark.It can work for a long time only with a small battery attached to it.This company has always supported us, so thank you very much.I am waiting for your support. Thanks pcbway :)

Greetings to all, my name is Valentina Ramirez, I am currently a student of electronic engineering at the University of Buenos Aires, today I want to show you my degree project, which is a solar charge controller based on Maximum Power Point Tracker.I decided to develop this project due to the inefficiency presented by the use of chargers called PWM which, due to poor energy management, end up wasting around 25% to 35% of energy produced by solar panels, this is largely produced by the behavior that solar panels have to give their maximum power, which must have a specific voltage and currents in order not to saturate the cells of the panels.but what differentiates a normal solar charger from an MPPT solar charge controller?The answer is found in the objectives of the different solar chargers and how they are executed, as I had already explained, due to the behavior of the solar panels they are not a normal current source, but instead need a voltage and a specific current so that they can work at their maximum power, therefore if we connect a normal DC-DC source, which is also called a PWM charger, it will take out in a very abrupt way and without any control, all the energy it has, producing an abrupt drop in voltage in the solar panel that will ultimately be reflected in solar production.On the contrary, the MPPT charge controller will seek to charge the battery with all the energy that is being generated, but the key is that it does so in a manner controlled by a microcontroller, thus finding the point where the panel voltage drops. abruptly and avoiding it, in order to find the exact point where the voltage and current are maximum to achieve the maximum power.I said a moment ago that MPPT chargers need a microprocessor to control it, so which one will we use? For this design we will use an Atmega328 that will monitor, at high speed, the solar panel voltage, battery voltage, solar panel current and battery current, this microprocessor will be powered from the battery with a DC-DC source 5V based on LM2596Moving on to more technical words, all this will be possible thanks to two resistive dividers that will be sensing the voltage of the batteries and that of the solar panels, additionally we will have two current sensors type ACS712-30A which will be capable of measuring currents of up to 30 amps. and transients of up to 100 amps, the reason for having both the voltage and the current of the solar panel monitored is because the system needs to calculate the current power by varying the cycle of the source PWM to modify the load and find the point full power.The reason for measuring the battery voltage and current is simply to control the maximum values ​​set in the program, which would be the maximum battery voltage and the maximum charging current, highlighting that this system can work to charge any type of battery. battery, already Li-ion, LiFePO4, lead acid, gel, open batteries, among others, of course modifying the desired charging algorithm for charging the different types of batteries, in addition to that the system is open to BMS implementations for example To control the cell-by-cell charge in lithium batteries, thank you for your attention, if you have questions about the design or anything else, write in the comments, I will be happy to answer you.

My project is about a smart speaker.I am going to make this project for my school project. It works as a virtual assistance. We can ask any questions to this. And we can also play music, control the home appliances etc..This speaker contains a raspberry pi 0 w as the CPU. But raspberry pi 0 w doesn't have audio in and out functionality. So for that I going to use a USB sound card. And it contains a 50+50 watts audio amplifier for good music experience. The audio amplifier also made by me. For that I made a PCB circuit in EasyEDA and i am goinh to order the pcbs in PCBway.This is the link to the gerber file and all of the details of this project:- https://drive.google.com/folderview?id=1GTlP8Gy7fXCkRDZ8sw9RJ-aB6YBXZV5_So to make this project I need the sponsorship from PCBway to provide me some beans to redeem a raspberry pi 0 w from PCBway gift shop and some coupons to order the pcbs.

I am going to make a video in youtube about homemade alexa. Alexa is a smart speaker and a virtual assistance.And it is selled by amazon but it cost above 8000.So i am going to build it within 3500 rupees($45).It is 5 times larger than original alexa. It has 40+40 watt speakers and 50+50 watt audio amplifier.This alexa is controlled by raspberry pi 0 w which is a cheapest tiny computer.For the audio input i am going to use USB mic.And for the audio out put raspberry pi 0 w has no audio jack or audio functionality.But the raspberry pi 0 w will give analog audio output from the GPIO pins and there is a problem it will give lot of noise so, for that i am going to make a low-pass filter using some resistance and capacitors.So now we have audio input and output functionality.Now to bring alexa to raspberry pi we need to create a developer account in amazon here https://developer.amazon.com/ .After that we need to install noobs os in raspberry pi. And then by using some commands we can install alexa in our raspberry pi.Then we should complete our circuit and for the power i am using 12volt rechargeable battery because our audio amplifier needs 12volt and to power up the pi i am using 12 volt to 5 volt converter.For the notification ring i am using neopixel strip and epoxy resin art kit to make it translucent.For the enclosure i am going to use 6 inch PVC pipe and for the top and bottom covering lid i am going to use plywood or mdf board.Now our alexa is ready we can ask anything to alexa.If pcbway sponsor for me I will tell some lines about PCBway in the youtube.

Hello. My name is Ivan develop various electronic devices as a hobby. My instagram page @domdevice.I want to make a digital electronic device that will show the current time and temperature inside the room. This project differs from the others in that the silkscreen is applied in the form of two hearts. The large heart has a main 7-segment LED display, and the small heart has fourteen red LEDs. The project I will do on an 8-bit STM8S103F3P6 microcontroller, the temperature sensor will be used by the DS18B20 because it is quite accurate and common. RTC use DS3231.Top side:Bottom side:For main display HT1628 led driver on SPI interface. To control the LEDs, I will use the hardware interface of the SPI microcontroller together with the 74HC595 chips, also known to everyone. I plan to display the time and temperature in a shift mode, and I will try to make different lighting effects for the LEDs. For example, a running light or a smooth switching on and off of LEDs using the PWM timer of the microcontroller. As a power supply for the device, you can use 5V from a USB computer if you use it in the office or almost any charger for cell phones with 5V 1A. You can set the time, change the brightness of the display and the brightness of the LEDs separately in a simple menu. To navigate through the menu, I will use several buttons. In general, this is an electronic device with a romantic theme, as its design is very unusual.I want to develop a project so that it is not just beautiful to look at but also useful to use. There are a lot of ordinary projects of hearts on LEDs, and it will quickly get boring and the clock and thermometer in the shape of a heart can be used daily at home or at work. Moreover it can remind you of the love of a guy for a girl well or vice versa :) it does not matter. In order for me to be able to do this project, I ask the PCBWay company for sponsorship. Let's make our world a little better and brighter together. Sincerely, Ivan.
