evaluation screen

The screen looks awesome and will be very helpful for me. Thank you for the squeegee card to help spread the solder paste. That was very considerate and thoughtful. Thank you PCBway team!!! attached is a picture of the screen with the solder pads from the pcb shown under. I think I have found my new prototype pcb and screen shop. I am a very happy client =D



Jul 26,2019
