Revised Custom ADS1256 board

This is the revised version of my previously built custom ADS1256 board. I fixed all the issues I had with the previous board and added a few tiny extra things. I also went for the black silkscreen. I recommend this color if you want to give more emphasis for the components and want to have the silkscreen "hide" in the background. It does not give as strong contrast with the green PCB as the white silkscreen but it is still readable. This time I also gave a little challenge to PCBWay: I "melted" my traces and I put teardrops around the tabs. The designed traces became more curved and the teardrops added some complexity to them as well. Nevertheless, the boards turned out great, I could not notice any issues with them. The mounting pads are also great as well as the outline of the board. Smooth and nice cutting. I am satisfied, thank you!











Jun 11,2022
