RS232 to RS485

Small scale protocol conversion pcb to fit inside off the shelf db9 to rj45 connector. PCB is manufactured to highest quality. The purple silkscreen is great, please make this a value option all the time. The price was good for the small batch I ordered. Pre tined pads took solder paste nicely with string adhesion.


Aug 21,2026
