PCB christmas three decoration

As always, PCBWay's work was wonderful. The silkscreen in the bottom of the board looks great and even the smallest texts are readable. In the top of the board, however there is a problem with the printing of the silk which I'm sure is due to some mistake I've made with de layers in the PCB design software. I wanted the cat and the border defined in the silk to be on top of the copper layver, but as I said, that probably was a problem related to my original design.



Feb 13,2023
70 viewsReport item
