NRC2026 68008 CPU Board

CPU board to run a M68008 on RCBus. PCB was excellent, we had a few issues with our design, but the board was not at fault. Went together nicely with all things well within tolerance. The PCB edges are particularly nice, they are polished or something as they are completely smooth. Using some surface mount component the boards happily handle the abuse of a hot plate and rework station. Not a simgle blemish or issue arose. Couldn't be happier.
