MakerIoT2020 MCU-8266-12E IoT Controller PCB

The PCB's were manufactured exactly as I designed them. I was initially quoted 3 to 4 days, but it seems that the production was finished in just 2 days? Perfect. The biggest delay seems to have been the shipping :) Even with that, It still arrived exactly 6 days from the time of order. Let us look a bit closer at the PCB then... Packaging was well done, Boards were packed in a vacuum-packed bubble wrap plastic. I selected a black solder mask. This is evenly applied, Well done there. The White silkscreen is perfect, with no smudges or other defects. Both ground planes are correctly placed. All component footprints are as designed. This board has 10 mains isolation cutouts, in complex irregular shapes. They were executed flawlessly! Overall, I would say a 10/10. Thank you







Aug 21,2021
888 viewsReport item
