Main Control Board

I'm very happy with how this project turned out. The PCB quality was excellent, the stencil made assembly straightforward, and the first bring-up went smoothly. I'd also like to thank Liam and the PCBWay team for their helpful support throughout the project, especially with the RF stack-up recommendations and stencil configuration. This board is part of my TrinityTrack6000 project, a modular embedded platform currently under development for a custom RC tracked vehicle. Looking forward to continuing the development with the next hardware modules.


Jul 20,2026
