MQTT Dante controller v2.1 base board

SMT soldering accurate. Watchful eye during engineering assembly revealed a component orientation error and us such has been corrected with nothing more than an online chat and email. Changes to BOM communicated efficiently and quote updated with no delay. Preparation of ready product took shorted than originally estimated making the whole project moving quickly. Fully functional device build took under one hour to program and complete.



Dec 23,2023
